Test Facilities

Testing – How well is CCI Equipped

High Voltage Test:

   400 kVacHigh Voltage test equipment.

   400 kVdc High Voltage test equipment.

Partial Discharge Test:

   Screen Room for PartialDischarge test equipment for doing test upto maximum 400 kV.

Impulse Test:

   2500 kV 1.2 / 50 μs impulse generator

Conductor Resistance Test:

   Conductor Resistance Bridge for measurement of resistance upto minimum of 1 µΩ.

Other Test:

   Well equipped physical & chemical lab for testing of all physical & chemical tests as per all IS/IEC specification for electric cables upto 400 kV.



Quality Certification by Independent Agencies

Complete Type Testing by CPRI, Bangalore and ERDA, Vadodara, and CMRS, Dhanbad on our following product samples :
   PVC Cables: IS : 1554 (Part : I & II) 1.1 kV, 3.3 kV, 6.6 kV & 11 kV
   XLPE Cables: IS : 7098 (Part – I) 1.1 kV (E)
   XLPE Cables: IS : 7098 (Part – II) 3.3 kV, 11KV, 22 kV & 33 kV
   XLPE Cables: ISC : 60502 (Part – I, Part – II) upto 30 kV
   EHV XLPE Cables: IEC – 60840, IEC 62067, 66 kV to 400 kV
   Elastomer Cables: IS : 9968 (Part I & II) 1.1 kV, 3.3 KV, 6.6 kV & 11 kV
   HT & LT Capacitors: IS : 13985 & IS : 13585
Test Equipments (Physical And Chemical)
   Tensile Testing Machine: Instron Ltd.Uk
   Thermo Gravimetric Analyser: T.A. Instruments USA
   Differential Scanning Calorimeter: T.A. Instruments USA
   Rheometer: Monsanto Ltd. U.K.
   Ozone Concentration Test Equipment: Gorden Solution India
   Escr Test Chember: Davenport Ltd. Uk
   Ultra Low Temp Cabinet: Revco USA
   Accelerated Weathering Tester: Q Panel Co USA
   Infrared Spectrometer: Perkin Elmer USA
   Fourier Transform Infrared Spectrometer: Perkin Elmer USA
   High Performance Liquid Chromatograph: Perkin Elmer USA
   Atomic Absorption Spectrometer: Perkin Elmer USA
   Cold Elongation Test Apparatus: Lab Tech India
   Multi Cell Air Oven: Wallace UK
   Air Oven: Barlow Whitney UK

Frls / Lszh Test Facility
   Oxygen Index Test Equipment: Stanton Red-Croft UK
   Halogen Acid Gas Evoluation Test Set: S.A.Associate India
   Swedish Chimney Test Set: Self Fabricated
   Flammability Test Set: Sew India
   Smoke Density Test Chamber: Ceast Italy
   Vertical Flame Test Apparatus: Yarsaley UK
   Toxicity Index Test Set: Fire Testing Equipment UK

Environmental Test Facility
   Organic Vapour Sampler: Enviotech Centre India
   Respirable Dust Sampler: Envirotech Centre India
   Stack Sampler: Enviotech Centre India

Test Equipments (Electrical Testing)
   80 kV,800 kVA Series Resonance Test Set: Hipotronics Inc. USA
   300 kV,3500 kVA Series Resonance Test Set: Hipotronics Inc USA
   100 kV,1000 kVA Series Resonance Test Set: Dielect China
   650 kV,19500 kVA Series Resonance Test Set: Hipotronics Inc USA
   300 kV DC High Voltage Test Set: Hipotronics Inc USA
   40 kV DC High Voltage Test Set: Bicco Test UK
   50 kV AC Breakdown Tester: Backman Instruments Inc. USA
   100 kV,250 Pc Partial Discharge Detector: Hipotronics Inc.USA
   Pulse Discrimination Type P. D. Detector: Hafley Switzerland
   300 kV 250 Pc Partial Discharge Detector: Hipotronics Inc. USA
   1000 kV,25 KJ Impulse Generator: Hipotronics Inc USA
   2400 kV, 120 KJ Impulse Generator: Hafley Switzerland
   5 Hz To 13 Mhz Impedance Analyser: Hewlett Packard USA
   300 Khz To 3 Ghz Networks Analyser: Hewlett Packard USA
   65 kV DC Impulse Type Fault Locator Cum HV Tester (Thumper): Biddle Instruments USA
   300 kV Schering Bridge: Tettex Instrument Switzerland
